● Upgraded version to 10W laser output
● 0.06mm High Precision for more vivid details
● Auto cross-positioning system, resume engraving after a power outage
● A solid choice for those new to engraving
● 18mm wood board, 15mm black acrylic in one pass
AtomStack A10 Pro V2 Laser Engraver
Highlights
General Detail
Materials Capabilities
Plug:US Plug
Package:Machine Only
Frequently Bought Together
AtomStack AC2 Wireless Camera for Laser Engraving and Cutting Machine
$129.00
$169.99
AtomStack FB2 Enclosure - Dustproof Laser Engraving Machine Protective Box
$99.00
$189.99
Atomstack Window Lens Replacement Lens for A6/12/24/48 Pro/Ultrta A10/A20/A40 PRO V2/Max A70 PRO/ A70 MAX Laser Engraver
$14.99
AtomStack R30 V2 Upgraded Infrared Laser Module for Metal and Plastic
$399.00
$549.99
Sold Out
Lightburn Software - Gcode License Key, for Most Diode Laser Engravers Machines On The Market
$99.00
$118.00
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
Specifications
| Product Model: | ATOMSTACK A10 PRO V2 |
| Device Size: | 7 x 10 x 7 inches |
| Engraving Size: | 410 * 380mm(16.14*15inches) |
| Working Principle: | Engraving / Cutting |
| Engraving Materials: | Wood, bamboo, cardboard, plastic, leather, PCB board, aluminum oxide, non-reflective electroplated and painted metal, 304 mirror stainless steel, dark glass, ceramics, cotton, slate |
| Cutting Materials: | Cardboard, non-woven fabric, wood, black acrylic, more thin plastic sheets, sponge |
| Input Power: | 50W |
| Output Power: | 10W |
| Maximum Speed: | 400 mm/s |
| Laser Wavelength: | 455±5nm |
| Engraving Accuracy: | 0.02mm |
| Spot Size: | 0.06*0.08mm |
| Joint Structure: | Guide Rails |
| Connection Method: | USB、Wi-Fi 2.4G |
| Supported Devices & Operating Systems: | Mobile: Android, iOS |
| Computer: Windows, mac OS | |
| Software: |
LightBurn、LaserGRBL、Atomstack PC、Atomstack APP
|
| Driver Update: | AtomStack APP or USB drive |
| Supported Formats: | JPG, JPEG, SVG, PNG, BMP, PDF, G-Code, DXF |
| Focus Adjustment Method: | Manual focus |
| Tip-over Alarm: | Tipping angle>15°, buzzer prompts |
| Cross Positioning: | Yes |
| Flame detection: | Yes, it requires support from the L2 Z-axis slider |
| Resume Engraving: | Yes |
| Quality Certification: | CE,FCC,RoHS,FDA,PSE |
